Metsä Wood UK’s head office in Boston, Lincolnshire is just one of many sites across the globe which specialise in providing sustainable, premium-quality wood products for many industries including the construction and industrial sectors. Metsä Wood employs around 1500 people and 2019 sales reached EUR 0.4 billion: its primary products are Kerto LVL (laminated veneer lumber) together with birch and spruce plywood.

Kawasaki Robotics’ new CPL180L has a tough act to follow: its predecessor, also a Kawasaki, performed 10,794,000 cycles in its 20 year career at the Metsä Wood plant

The four UK sites at Boston, Kings Lynn, Widnes and Grangemouth also supply machined softwood and panel material to the Merchant & DIY markets. Another key strength of the business is an associated revenue stream which makes good use of the wood shavings generated during the various manufacturing processes at the Boston site.

The shavings produced go into a sector which has proven both buoyant and resilient over the years: the equestrian market. Every year, thousands of tonnes of Metsä Wood ‘Hunter’ Woodshavings are used for bedding in stables across the country, where they are said to be received with unbridled enthusiasm by the occupants.

Once the loose shavings have been collated into bales using bespoke machinery at the Boston plant, the bales are removed from the line by a recently installed new Kawasaki robot and placed directly onto a 1200mm x 1200mm pallet ready for dispatch. To ensure that the load is stable, the robot must also rotate the bales through 90° as it stacks, a task easily performed whilst transiting from pick-up to deposit. The new robot, which was installed in August 2019, is a Kawasaki CP180L with associated HMI, which replaced an older robot, also a Kawasaki unit (a ZD130) that was originally installed at the plant in 2002. This machine had provided sterling service, and according to Metsä Wood Project Manager Andrew Burns, “Our records revealed that the Kawasaki robot installed in 2002 had completed 10,794,000 cycles, and it had performed superbly. We valued its reliability coupled with Kawasaki Robotics’ responsiveness and professional engineering approach. When we wanted a replacement for it in August 2019 there was only one place to go – Kawasaki – for another robot to last us the next 20 years or so”.

In a typical working day, around 1000 25kg bales are picked off the line and stacked safely using the necessary orientation changes  programmed into the new Kawasaki CP180L robot. Removing the old robot and placing the new one onto its plinth was straightforward according to Mick Middleditch of Higham Ferrers based RJC Projects, who were tasked with accessing the cell and swapping them over. “It was a trouble-free, like-for-like exchange that presented us with no problems or challenges”.

Metsä Wood’s Hunter Woodshavings horse bedding is a valuable part of the business

The installation, integration and programming of the newly installed CP180L was undertaken by industry experts KTM Systems of Liverpool. KTM Director Peter Mason has over 25 years in the business of robot installations and commissioning: “This job was identified as a critical one from the start. It was made clear that if this part of the manufacturing process was closed down for more than a few hours, production at the entire factory would come to a standstill. Our team set to work the moment RJC had placed the new machine in position and we had the new robot installed, programmed and commissioned well inside the stipulated window. It has been performing flawlessly since”.

Kawasaki Robotics’ Ian Hensman observed, “When our original ZD130 robot was installed at the Boston Metsä Wood plant almost 20 years ago, it represented the state-of-the-art at the time and it served our customer extremely well. The Kawasaki CP180L that has replaced it is faster and more accurate, but uses less energy than its predecessor. The reach is longer (at 3.255m) offering greater flexibility for users, and it is easier to programme. Further, this latest model also requires less maintenance too”.
