To operate large applications as efficiently as possible, users need to have constant information about the current status of devices and functions. The ACT20C module from Weidmüller enables such effective and strategic monitoring and optimisation of such systems and processes through AC and DC current readings.

Wind power installations are ideal candidates for the ACT20C. In a lot of cases wind farms are situated in remote locations on land and at sea subject to extreme weather conditions, so onsite and immediate maintenance and monitoring isn’t always possible. With the transducer, it is possible to implement more effective monitoring and observation from a distance. The transducer can contribute to a reduction in equipment ‘wear and tear’ with its ability to alter a turbine’s motors (for pitch adjustment), device heaters or brakes, with information concerning their utilisation and operating performance. The ACT20C is a crucial piece of technology that detects overloads or engine and brake anomalies at an early stage. It can also respond promptly to poorly performing cooling fans or rotor blade de-icing.  Ice build-up on the rotor-blades can reduce energy efficiency because the weight of frozen material throws the angle of the technology out of alignment leading to wasted energy and reduced effectiveness.

The new ACT20C current measuring transducer uses True RMS, to produce accurate readings of DC and AC currents, even when the waveforms get distorted. Information about the connected load’s operating behaviour is also determined during its process. The result is a significant increase in transparency for error detection and fault analysis. The ACT20C current accuracy of = 0.5% (FSR) with additional detail on the connected load’s status made available via Ethernet. Software configuration is based on the FDT and FDT2 standards, which simplifies parameter setting, documentation and data backups.

Other important features to the ACT20C includes:

  • an input measurement range of 0 to 5/10 A AC (RMS) or DC and input frequency of 15 to 700 hz,
  • an output voltage of 0 to 5 V, 0 to 10 V, -5 to 5, -10 to 10 V and an output current of 0 to 20 mA, 4 to 20 mA, -20 to+20 mA,
  • facility to customise settings,
  • galvanic four-way isolation ,
  • an impulse to withstand voltage of 6.4 kV in accordance with IEC 61010-2-201 that guarantees a high level of process reliability,
  • available in two variants: ACT20C-CMT-10-AO-RC-S and ACT 20C-CMT-60-AO-RCS.

Configuration takes place through the ACT20C gateway with users gaining a complete overview of all process parameters via Ethernet. Gateway users have a complete overview of all process parameters via Ethernet, while station management featuring ‘plug & produce’ and ‘hot swapping’ will speed up installation and any maintenance work. The gateway is also fully operational at a wide range of temperatures from -25 degrees to + 60 degrees, opening up a world of opportunity for Weidmüller clients everywhere.

For further information visit email or call 0845 094 2006.
