The control components featured in the RAFI series RAFIX 22 FS enable new operating unit designs thanks to their low mounting depth of only 9.2mm. What’s more, the elements offered in this series – pushbuttons, selector switches, keyswitches, lenses and emergency stop pushbuttons according to DIN EN ISO 13850 – can be combined with front rings in various colors to allocate individual recognition values to switch functions.

The switch components are available as circuit board versions or with quick-connect terminals for direct connection with wiring. The PCB variants can be combined with other components such as displays or short-travel keyswitches on a common printed circuit board.

For actuator illumination, a 3mm LED can be installed in the middle channel of the switch component. On the other hand, contact blocks with quick-connect terminals are an economical alternative for applications where the use of printed circuit boards is inefficient or not feasible. In addition, the simple plug-in principle allows prefabrication of cable trees with switch components. Since all actuators provide a minimum IP 65 protection they are suitable for many applications.
